Specification
仕様書
Horn Speaker Model No.UF-770
And
Driver Unit Model No.UF-D50N
Dimensions
UF-770
Diam. 130mm×120mm
UF-D50N
Diam.
Length 157.5mm
φ109mm Length 65mm
Overall Length
About 180mm （UF-770 & UF-D50N）
Rated Input
50W
Impedance
16Ω
Sound Pressure Level
more than 102dB (at 1m1W input、4
Frequency Response
300Hz ～ 5kHz (Deviation 20dB)
Mass
UF-770
650g
UF-D50N
1kg
UF-770
Munsell N5.5 approx. Gray
UF-D50N
Munsell N4.0 approx. Gray
Finish
point average at 1kHz･1.5kHz･2kHz･3kHz
)
BUSINESS
JG03
Subject to change for improvement without notice.
