角ピンプラグ 1.0x1.0mm Plug Header

www.connect.co.jp
角ピンプラグ 1.0x1.0mm
Plug Header
Specifications
Dielectric strength
Insulation resistance
Contact resistance
Current rating
Operating Temperature
:
:
Polyester UL94V-0
Phosphor Bronze
Au flash over Ni plating
Max proccesing temperature
230℃ for 60second, 260℃ for 10second
ST - □□
ST : Single in line,Straight
SR : Single in line,Right Angle
IPB10 -
Number of positions : P
Single in line : 4~50
DT
DT : Dual in line,Straight
DR : Dual in line,Right Angle
ST : Single in line,Straight
1.0xP
- □□
Number of positions : P
Dual in line : 6~100
(2x3~2x50)
DT : Dual in line,Straight
1.0x(P-1)
1.0x(P/2)
1.0x(P/2-1)
1.27
□0.30
3.1
1.0
□0.30
(5.3)
1.8
1.0
2.5
1.8
(5.3)
IPB10 -
Material
Insulator
Pin :
AC300Vrms
:
1000MΩmin
:
20mΩ max
:
1.0A
: -40℃~+125℃
1.0
1.0x(P-1)
2.5
∅0.60
1.0
DR : Dual in line,Right Angle
SR : Single in line,Right Angle
1.0xP
1.0x(P/2)
1.0x(P-1)
1.8
1.8
1.0x(P/2-1)
1
1.0
2.6
2.6
3.1
1.27
1.8
PC board layout
PC board layout
1.8
1.0x(P/2-1)
1.0
1.0x(P-1)
∅0.70
1
∅0.70
1.0
12D1
1.0
1.0
www.connect.co.jp
角ピンソケット 1.0x1.0mm
Header Socket
Specifications
Dielectric strength
Insulation resistance
Contact resistance
Current rating
Operating Temperature
HSB10D -
ST
ST : Single in line
Material
Insulator
Pin :
AC300Vrms
:
1000MΩmin
:
20mΩ max
:
1.0A
: -40℃~+125℃
Polyester UL94V-0
Phosphor Bronze
Au flash over Ni plating
Max proccesing temperature
230℃ for 60second, 260℃ for 10second
- □□
HSB10D -
Number of positions : P
Single in line : 4~50
:
:
DT
- □□
DT : Dual in line
Number of positions : P
Single in line : 4~50
Dual in line
: 6~100
(2x3~2x50)
1.0x(P/2)+0.5
1.0xP+0.5
1.0x(P/2-1)
1.0x(P-1)
2.1
2.1
2.5
1.0
1.5
2.4
2.4
1.0
0.3xt0.1
0.3xt0.1
PC board layout
PC board layout
1.0x(P-1)
1.0x(P/2-1)
1.0
∅0.60
∅0.60
1.0
1.0
ソケット
3.1
2.1
基板
3.1
かん合時の
基板間高さ
表面実装タイプ
も揃えています
2.1
基板
ソケット
1.0
12D2
*ソケットに挿入するプラグピン長さは
1.8mm~2.1mmです
